Atlas Residential Vertical Platform Lift
| Your Price | $4,799.00 |
|---|---|
| Regular Price | $6,500.00 |
|
Warranty Info Click Here |
|
The AmeriGlide Atlas Residential Vertical Platform Lift makes it possible for scooter and wheelchair users to get in and out of their homes on their own. The Atlas is designed for year-round use and can withstand the harshest weather. It has a smooth, quiet worm-gear drive that is capable of lifting 550 pounds. The Atlas is also safe, easy to use, and easy to install.
- Standard 72" lift height, 96", 120", and 144" available
- Non-load-bearing safety nut on lift shaft
- Automatic folding entry ramp
- Emergency manual operation
- 8 feet/minute lift speed
- Expanded metal platform with full under platform visibility and non-skid surface
- U.L. and C.S.A. certified
- Direct worm gear/acme screw drive
Please call us if you need assistance. We have a team of experts that can answer any questions about your specific application, the accessories you need, or anything else about the vertical platform lifts we sell.
| Lifting Capacity | 550 lb |
| Standard Lift Height | 72" |
| Maximum Lift Height | 144" |
| Portable | No |
| Arrives Assembled | No |
| Drive System | Direct Worm-Gear & Screw-Nut |
| Optional Drive Systems | None Available |
| Battery Powered Option | Yes |
| Constant Pressure Platform Control | Yes |
| Emergency Stop Platform Control | Standard |
| Alarm Button | None Available |
| Keyed Platform Control | Standard |
| Call-Send Controls | Not Included |
| Optional Call-Send Controls | Call-Send, Call-Send with Key, Toggle, Toggle with Key |
| Platform Type | Expanded Metal |
| Platform Size | 34" x 54" |
| Optional Platform Sizes | 40" x 54" |
| Platform Configuration | Straight-Thru Access |
| Optional Platform Configurations | Adjacent Access |
| Upper Landing Gate | Optional |
| Upper Access Ramp | None Available |
| Lower Access Ramp | Automatic Folding |
| Grab Rail | Standard |
| Guard Panel | Optional |
| Maximum Stops | 3 |
-
Lifting Height
-
$0.00
72" Maximum Lift Height
-
$1,700.00
96" Maximum Lift Height
-
$2,250.00
120" Maximum Lift Height
-
$3,000.00
144" Maximum Lift Height
-
-
Tower Orientation
-
$0.00
Tower On The Left
-
$0.00
Tower On The Right
-
-
Power Source
-
$0.00
AC Powered
-
$1,571.98
AC Powered with DC Battery Backup (Batteries Not Included)
-
-
Platform Size
-
$0.00
34" x 54" Platform
-
$0.00
40" x 54" Platform (For Adjacent Access Only)
-
-
Platform Access
-
$0.00
Straight Through
-
$228.58
90° Adjacent Access
-
$471.43
Same Side Entry / Exit (requires Solid End Wall)
-
-
Platform Gate
-
$0.00
No Platform Gate
-
$928.58
Platform Gate with Interlock
-
-
Platform Controls
-
$0.00
Paddle Controls with Emergency Stop Button
-
-
Platform Control Options
-
$0.00
Keylock for Platform Controls
-
$100.00
Backlit Emergency Stop Button
-
-
Platform Options
-
$0.00
Automatic Ramp for Ground to Platform Transition
-
$185.72
Solid Hand Rail
-
$314.29
Solid End Wall
-
$314.29
Control Wall Extension
-
$271.43
Solid Platform
-
$485.72
Solid Platform with Safety Pan
-
$107.15
Inside Grab Bar - 48"
-
-
Landing Controls
-
$135.00
Pushbutton Call Control (each)
-
$232.50
Keyed Pushbutton Call Control (each)
-
$195.00
Toggle Call & Send Control (each)
-
$285.00
Keyed Toggle Call & Send Control (each)
-
-
Landing Gate
-
$0.00
No Landing Gate
-
$1,185.72
Left Swing Landing Gate - with Interlock & Keyed Pushbutton Call Control
-
$1,185.72
Right Swing Landing Gate - with Interlock & Keyed Pushbutton Call Control
-
$1,242.86
Left Swing Landing Gate - with Interlock & Keyed Toggle Call/Send Control
-
$1,242.86
Right Swing Landing Gate - with Interlock & Keyed Toggle Call/Send Control
-
-
Landing Gate Options
-
$378.58
Oversized Upper Landing Gate Upcharge
-
-
Interlocks
-
$450.00
Additional Interlock (each)
-
-
Other Options
-
$450.00
3 Stop Wiring Charge
-
$334.98
Batteries for Backup System
-
-
Additional Delivery Services
-
$0.00
Trucking Terminal or Commercial Location with Loading Dock
-
$279.00
Liftgate Delivery, 28" & 52" Units Only
-
$109.00
Limited Access Delivery Charge
-
$0.00
AK, HI, PR, or International - Please Call for Quote
-
