- Rack and pinion drive
- No slack cable lock-ups
- Battery operated
- Fast and easy installation – plug and play
- Aluminum rail instead of steel T-rail
- No separate machine room required
- No remote mounted controller
- On board diagnostic troubleshooting LED light
- 20" Wide x 20" Deep x 30" High – 200 lbs capacity
- 24" Wide x 24" Deep x 30" High – 200 lbs capacity
- 30" Wide x 30" Deep x 36" High – 275 lbs capacity
- Optional stainless steel car
- Warranty 5 years on motor and gear, and 2 years on all other parts
Warranty
2 years for batteries
5 years for all other component parts
Labor reimbursement is not covered by this warranty
If defects were the result of improper installation, non-normal use, freight damage, or other terms failing to meet the conditions of this Limited Warranty as described herein, the defects would not be covered.
Options Available
- Stops
2 Stops $0.00
3 Stops $858.00
4 Stops $1,422.00
- Car Door Placement (in reference to the track)
- Car Dimensions
20"W x 20"D x 30"H (200 LB Capacity) $0.00
24"W x 24"D x 30"H (200 LB Capacity) $715.00
30"W x 30" D x 36"H (275 LB Capacity) $1,215.00
Custom Cab Size $1,786.00
- Car Material
Standard Coated Steel Panels (any size) $0.00
Stainless Steel Panels Must Match Car Dimensions Above $0.00
Stainless Steel 20"W x 20"D x 30"H $2,429.00
Stainless Steel 24"W x 24"D x 30"H $2,715.00
Stainless Steel 30"W x 30" D x 36"H $3,286.00
Stainless Steel Custom Size $4,000.00
- Car Shelf
Up to 4 Total $0.00
No Optional Car Shelf $0.00
Adjustable Wire Rack Car Shelf $143.00
Sliding Shelf $500.00
Metal Powder Coated Shelf $215.00
Stainless Steel Car Shelf $643.00
- Call/Send Controls
1 RF Call Station Per Stop $0.00
Key Lock on RF Call Station $72.00
Car Here Indicator on RF Call Station $143.00
- First Landing Door Locations
Front $0.00
Rear $0.00
Left Side $0.00
Right Side $0.00
- Second Landing Door Locations
Front $0.00
Rear $0.00
Left Side $0.00
Right Side $0.00
- Third Landing Door Locations (if 3 or 4 Stop)
None $0.00
Front $0.00
Rear $0.00
Left Side $0.00
Right Side $0.00
- Fourth Landing Door Locations (if 4 Stop)
None $0.00
Front $0.00
Rear $0.00
Left Side $0.00
Right Side $0.00
- First Landing Hoistway Door Swing
Door Hinged on the Right $0.00
Door Hinged on the Left $0.00
- Second Landing Hoistway Door Swing
Door Hinged on the Right $0.00
Door Hinged on the Left $0.00
- Third Landing Hoistway Door Swing (if 3 or 4 Stop)
No Third Stop $0.00
Door Hinged on the Right $0.00
Door Hinged on the Left $0.00
- Fourth Landing Hoistway Door Swing (if 4 Stop)
No Fourth Stop $0.00
Door Hinged on the Right $0.00
Door Hinged on the Left $0.00
- Additional Options
Automatic Car Lighting $108.00
Automatic Homing $429.00
Select Landing for Automatic Homing (if selected above, bottom is #1) $0.00
- RDI Interlock
RDI Interlocks (1 per Stop Included) $0.00
NOTE: if any stop has more than one access opening, order additional Interlocks $0.00
Additional RDI Interlocks $429.00
Upgrade RDI to Commercial Interlock (per Interlock) $358.00
- Track
10' of Extruded Aluminum Track Included $0.00
Extra Track Per Foot (Over 10') $65.00
- Hoistway/Access Doors
No Optional Hoistway Doors $0.00
Unfinished Poplar Hoistway Door $500.00
Unfinished Maple Hoistway Door $715.00
Machine Access Door (20" x 20") Includes RDI Interlock - Unfinished Poplar $929.00
Machine Access Door (20" x 20") Includes RDI Interlock - Unfinished Maple $1,143.00
- Dumbwaiter Shipping
Shipping to Nearest Freight Terminal/ Loading Dock In or Near Your Zip Code (lower 48) $0.00
Call for Price to ship to Alaska or Hawaii $0.00
- Optional Fire Proof Landing and Machine Access Doors
Stainless Steel (#4 finish) Swing Door - 1.5 Hour Fire Rated $0.00
20" W x 30" H - Right Hand $1,453.00
20" W x 30" H - Left Hand $1,453.00
24" W x 30" H - Right Hand $1,453.00
24" W x 30" H - Left Hand $1,453.00
30" W x 36" H - Right Hand $1,617.00
30" W x 36" H - Left Hand $1,617.00
Machine Access Door $0.00
18" W x 18" H Stainless Steel - Right Hand $1,000.00
18" W x 18" H Stainless Steel - Left Hand $1,000.00
- Mounting Surface For Optional Fire Proof Doors
Dry Wall Mounted $0.00
Masonry Wall Mounted $0.00
- Freight for Optional Fire Proof Doors
No Optional Fire Proof Doors Ordered $0.00
Freight for Up to 3 Doors $1,001.00
Freight for 4 Doors $1,077.00
Freight for 5 Doors $1,154.00
Freight for 6 or More Doors (call for quote) $0.00
Call for Price to Ship Outside the Contiguous 48 US States $0.00
- Delivery Option for Optional Fire Proof Doors
Liftgate Service (if needed for doors at the delivery point) $0.00
